MAY-Z6000 High Capacity Mineral Rock Density Porosity Water AbsorptionTester
MZ-Z6000-CZ
| MZ-Z6000-SZ
| MZ-Z6000-XD
|
Standard Specification:
According to ASTM C39, ASTM C128, ASTM C127, AASHTOT84. JIS, GB/T35160. 1, GB/T23561 specifications. Adopt Archimedes buoyancy method, apply vacuum saturation method, boiling saturation method, and particle immersion method to quickly read the measurement value.
Application:
Various mineral rock blocks such as porous rock, shale, marble, quartz stone, iron ore, ore powder wood, etc.
Features:
1. Digital display direct reading, without manual calculation, directly display parameters such as density and volume.
2. Porous water-absorbent ore, marble, ore powder and similar products can all be measured quickly.
3. The German original HBM sensor is used for accurate measurement, easy operation, stable and durable
4. It has the function of actual water temperature compensation, which can adapt to changes in the test environment.
5. The density of the medium can be set, water is used as the medium, and other liquid mediums can also be used.
6. It adopts one-piece molding large-capacity measuring table, corrosion-resistant and drop-proof, and it can be replaced free of charge for life.
7. Equipped with a special wind and dust cover, which is easy to combine and durable.
8. With RS-232C communication interface, it is convenient to connect PC and printer, and MZ-P1 printer can be selected to print measurement data
9. Mayzum-Smart multi-group sample measurement system is optional, which can measure 10 groups of data at a time to achieve high-efficiency measurement. One-click printing of A4 standard data reports for material disintegration in a second, storing more than 100,000 groups of data.
Technical parameters:
Note: A large range of large-scale density meters can be customized according to customer needs, and the maximum can be customized 6-30kg)
Brand | MAYZUM（Warranty for 3 years） | |||||
Model | MZ-Z150 | MZ-Z300/MZ-Z600 | MZ-Z1200/MZ-Z3000 | MZ-Z6000 | ||
Weight accuracy & Max load | 0.001g ; 150g | 0.005g ;300g | 0.01g ; 1200g/3000g | 0.01g ; 6000g | ||
Density Precision | 0.0001 g/cm3 | 0.001 g/cm3 | ||||
Density Range | 0.001~99.999g/cm3 | |||||
Water absorption porosity and oil content accuracy | 0.01% | |||||
Principle | Archimedes principle of drainage | |||||
Testing Time | About 5 seconds | |||||
Testing Procedure | 1. Put the sample on the measuring table and press MEMORY to save 2. Put the sample into the water measuring table and press the MEMORY key to save it. The instrument directly displays the density, volume. Porous material test procedure according to national standard, please refer to random instruction | |||||
Results Displayed | Bulk density, wet density, apparent density, apparent porosity, water absorption, open pore volume, sealed pore volume, total porosity | |||||
Parameter Setting | Water temperature setting, medium liquid density setting | |||||
Calibration | One-key automatic Calibration | |||||
Output Method | RS-232C standard communication interface, convenient for test data output and printing | |||||
Temperature and Humidity Range | Allowable ambient temperature: 0~45℃; Allowable relative humidity: within 80% | |||||
Power Supply | AC~220V / 50HZ（Export power supply needs to be customized, please indicate before ordering） | |||||
Standard accessories | ①Host computer ②Sink ③Measuring table ④Tweezers ⑤Bubble dropper ⑥Weight ⑦Power transformer ⑧Particle measuring accessories ⑨Floating material measuring accessories | |||||
Optional accessories | MZ-P1 printer Mayzum-Smart multi-sample measurement system | |||||
Other Parameters | Outer packing size: 395*195*330mm Tester size: 210*195*185mm Net weight : 3.5kg Gross weight: 4.5kg HS code : 90160090 | |||||
