Intelligent powder metallurgy density, porosity and oil content analyzer
Model: MAY-Entris120 MAY-Entris220
It is specially designed for the powder metallurgy industry and can detect all types of powder metallurgy workpieces.
Application industries
Powder metallurgy, precision ceramics, graphite carbon brushes, precious metal detection, rubber, plastics, university research institutes, etc.
Technical Parameters:
1. Weighing range: 0.0001g~120g (optional range: 120g, 220g, 320g, 3kg)
2. Weighing repeatability error: ±0.0002g
3. Measurement accuracy of density and specific gravity: 0.0001g/cm3
4. Analysis of oil content and porosity: 0.01%
5. Volume analysis: 0.0001cm3
Types of powder metallurgy oil content density tester
MZ-P300/P600Accuracy:0.001g/cm³ | MZ-P150 （Equipped with windproof and dustproof cover）Accuracy:0.0001g/cm³
|
Patented intelligent May-Entris120 Accuracy:0.0001g/cm³ | MZ-P3000（Size can be customized on demand） Accuracy: 0.001g/cm³
|
Features:
1. Designed specifically for small powder metallurgy workpieces, using a measuring host imported from Germany, with the highest measurement accuracy, reliability, and stability in the industry;
2. It can measure more than 10 groups of samples at the same time, and degrease the samples at the same time; Compared with the traditional instrument can only measure one sample at a time, this instrument can save at least 10 times the time, and the measurement efficiency is very high;
3. It can save, view, edit, and delete the measurement results of each time, generate test reports in PDF format with one click, print reports online, and export data to Excel, etc.;
Main function:
1. Can measure more than 10 groups at the same time
2. The oil content, oil absorption, bulk density and volume of oil-bearing powder metallurgy workpieces;
3. Density, specific gravity and volume of dense powder metallurgy die castings, forgings, MIM injection parts, etc.;
4. Porosity, bulk density, open porosity, closed porosity, oil absorption, and pore volume of water-absorbent powder metallurgy workpieces
5. It can measure the relative density of medium liquid (such as water) and saturated liquid (such as lubricating oil)
Measurement interface:
Other function:
1. The test report in A4 format will be automatically printed after the measurement
2. It also can be printed as 58mm self-adhesive label
3. Optional accessories Soxhlet extractor (applicable to Japanese standard JIS)
